Xtreme Ladder Model 17

12317


XTREME MODEL 17 with Ratchet Levelers

The completely new Little Giant Xtreme™ is the pinnacle of Little Giant’s 40 years of engineering the strongest, safest, most versatile ladders in the world. The Xtreme combines the strength, safety and versatility of the classic Little Giant Ladder with several new groundbreaking features, including the Comfort Step™, AirDeck™ workstation, user-friendly Rock Locks™, and the stronger, safer Quad-Lock™ hinges.

The integrated Comfort Step serves as a spacious, comfortable standing surface at any height or configuration. When coupled with the AirDeck’s safety handrail, the Comfort Step literally makes you feel like you are standing on solid ground.

The Xtreme comes with Little Giant’s patent-pending Ratchet Levelers, which adjust hands-free in seconds. These integrated leg levelers allow the operator to adjust to uneven ground in mere seconds. And when the job is done, the levelers retract into storage position. The levelers add only 4 pounds to the ladder weight and offer nearly 8 ½ inches of leveling adjustment.

Each side of the Xtreme telescopes independently, giving you the option of several sizes of stepladders, from 4 to 9 feet depending on the model you select. You can also adjust one side to work on staircases or uneven surfaces or as a 90-degree stepladder. The Quad-Lock hinge allows you to use the ladder as a stable, wide-based, multi-height extension ladder. Finally, the inner and outer ladder assemblies separate to form two trestles for a time-saving scaffolding system. The Little Giant Xtreme is the finest multi-use ladder system in the world.



Model 17 w/Ratchet Levelers™ Model 22 w/Ratchet Levelers™ Model 26 w/Ratchet Levelers™
Model Number 12317 12322 12326
Weight Capacity 150kg 150kg 150kg
A-Frame Min. Height 1.21M 1.52M 1.82M
A-Frame Max. Height 2.1M 2.74M 3.35
A-Frame Max. Highest Standing Level 1.8M 2.4M 2.92M
Extension Min. Height 2.74M 3.35M 3.96M
Extension Max. Height 4.57M 5.79M 7.0M
Extension Max. Highest Standing Level 3.5M 4.75M 5.91M
Storage Height 1.43M 1.73M 2.04M
Storage Width at Base 0.33M 0.68M 0.82M
Storage Depth 0.22M 0.22M 0.22M
Max. Footprint 1.58 2.01 2.16
Rung Size Single Section 4cm 4cm 4cm
4cm 4cm 4cm
Rung Size Double Section 0.08M 0.08M 0.08M
Palm & Hinge Lock System Quad-Lock™ Quad-Lock™ Quad-Lock™
Spreader System Hinge Lock Hinge Lock Hinge Lock
Extension Lock System Rock Lock® rung fasteners Rock Lock® rung fasteners Rock Lock® rung fasteners
Tip & Glide™ Wheels Yes Yes Yes
Scaffolding Position Yes Yes Yes
90-Degree Ladder Yes Yes Yes
Feet Co-Molded Snap-On Co-Molded Snap-On Co-Molded Snap-On
Material Aluminum Aluminum Aluminum
Ladder Weight 20kgs 23kgs 26kgs
Shipping Weight 23kgs 28kgs 32kgs
Warranty Limited Lifetime Limited Lifetime Limited Lifetime
Country of Origin Made in China Made in China Made in China
